2006 Jaguar X-TYPE repair manual

The 2006 Jaguar X-TYPE /X400 belongs to the X400 (2006–2010 in our shop) generation. 2006 is the first model year of the X400 in our shop. Not sure which version you have? Your VIN tells us.

2006 Jaguar X-TYPE factory repair manual (X400) – PDF for your VIN

The 2006 Jaguar X-TYPE (X400) factory repair manual, made for your VIN from Jaguar's factory service data: removal and installation steps, torque values, diagnostics and wiring diagrams for your exact X-TYPE. The 2006 X-TYPE was offered with five engines and three transmissions (listed below); the manual you get is for the combination in your VIN.

The Google Top Quality Store badge, without a subscription. Pay once for this manual; there is no monthly fee and nothing to cancel later.

The difference you get

• Manufacturer data: written by Jaguar, not rewritten by a third-party publisher
• Yours to keep: pay once and the PDF stays with you
• A PDF with working hyperlinks: click a reference in a procedure and you land on the wiring diagram, spec or step it points to. Most PDF manuals sold online are flat scans without them
• Complete wiring diagrams and connector views, not just the mechanical sections
• Works on any device, offline, and prints page by page for the garage
• A real person checks every order and the VIN before the manual is built

What this manual has that the owner's manual does not

The owner's manual stops where the repair starts. The factory repair manual picks up from there:

• Owner's manual: controls, warning lights, maintenance schedule, fluid types
• Factory repair manual: removal and installation steps, torque specs, diagnostic trouble codes, wiring diagrams and component locations

The 2006 X-TYPE belongs to the X-Type (X400) generation, model years 2001–2010. Most procedures are shared with the other years of this generation, but options, software and wiring changed along the way, which is why the manual is built for your VIN.

Engines available for the 2006 X-TYPE

• 2.0L Diesel
• 2.0L V6 Petrol
• 2.2L Diesel
• 2.5L V6 Petrol
• 3.0L NA V6 Petrol

Transmission options

• 5SP TRANSVERSE AUTO-JATCO/FPD
• 5 SPD MAN TRANS A EAO MTX75
• MANUAL 6 SPD MMT6 3 SHAFT TRAN

Your manual is built for your version only: the VIN tells us the exact engine and transmission.

Common work on a 2006 X-TYPE

• Rust repair and body panels
• Fuel pump, filter and lines
• Brake lines, hoses and master cylinder
• Ignition components and idle problems
• Suspension bushings and steering play
• Glow plugs and cold-start faults
• Diesel particulate filter regeneration
• EGR valve and cooler

What NHTSA records show for the 2006 X-TYPE

The U.S. safety agency NHTSA lists no safety recalls and 43 owner complaints for the 2006 X-TYPE. The factory manual has the procedures for the parts involved.

Most owner complaints concern: Vehicle Speed Control (9), Service Brakes (8), Fuel System (7), Gasoline (7), Tires (6).

On a 2006 vehicle the 10th character of the 17-digit VIN is “6”, a quick way to confirm the model year before you order.

Other years of the same generation: 2001 X-TYPE, 2002 X-TYPE, 2003 X-TYPE, 2004 X-TYPE, 2005 X-TYPE, 2007 X-TYPE, 2008 X-TYPE, 2009 X-TYPE, 2010 X-TYPE.

More Jaguar repair manuals: 2024 F-PACE, 2003 XJ V8, 2016 XE, 2009 XF, 2006 XJ, 2006 XK, 2018 E-PACE, 2017 F-PACE, 2014 F-TYPE, 2019 I-PACE.

What happens after you order

1. We check the VIN.
2. We compile the 2006 X-TYPE service information for it.
3. You receive one bookmarked, hyperlinked PDF by email in 12–24 hours.

Sections of the 2006 X-TYPE service manual

• General information, vehicle identification and lifting points
• Maintenance schedules, fluids and capacities
• Engine mechanical: timing, cylinder head, lubrication
• Cooling system
• Fuel system and engine management
• Ignition, starting and charging
• Emission controls
• Exhaust system
• Clutch and manual transmission
• Automatic transmission / transaxle
• Driveshafts, axles and differential
• Suspension, front and rear
• Steering
• Brakes and ABS
• Heating, ventilation and air conditioning
• Restraints and airbags
• Body, doors, glass and trim
• Lighting and instruments
• Electrical components and module locations
• Wiring diagrams
• Diagnostic trouble codes

Engine

Transmission

Your manual is built for the version in your VIN.

This video is for information. Your manual looks and works the same way, but it is not identical.

Free, by email in 12-24 hours.
