2016 Jeep Cherokee repair manual
$69.99
- Do the labor yourself. On most repairs the shop’s labor costs more than the parts. With the factory procedure you can do that part yourself.
- Built for your VIN. Your engine, transmission and options, so you don’t have to guess which section applies.
- Factory steps, specs and wiring. Repair procedures with illustrations, torque values and the complete wiring diagrams.
- Find any job in seconds. Searchable PDF with a full index and bookmarks.
- In your inbox in 12–24 hours. Yours to keep, on any computer, phone or tablet.
Description
2016 Jeep Cherokee repair manual - OEM Factory Repair Manual
The 2016 Jeep Cherokee (KL) factory repair manual, built from Chrysler's own service information for your VIN: every repair procedure, torque spec and wiring diagram for your exact Jeep. It covers the 2016 Cherokee KL with the 2.4 four-cylinder or the 3.2 V6 and the 9-speed automatic, front-wheel drive or Active Drive 4x4.
Look for the Top Quality Store badge. Google shows it next to factory-manuals.com, and we are the only store with that badge that sells you the manual itself, not timed access. Pay once and keep it.
By 2016 the KL's early transmission issues had been reduced with software updates, but the 9-speed still needs the correct fluid and check procedure. Front-wheel-drive and 4x4 models differ in the PTU, the rear drive module and the driveshaft, and the VIN tells us which you have.
Common jobs on a 2016: front control arm bushings, the PTU fluid change on 4x4s, the 3.2 V6's oil filter housing and the Uconnect radio. The wiring diagrams cover the full body and chassis electrical system.
How we make your manual. Chrysler sells access to its factory service information to owners and independent shops. We do that work for you: we open the service information for your VIN and build a PDF that matches your engine, transmission and options. It takes 12–24 hours. If your Jeep is apart right now, choose priority delivery and you get it in 4–6 hours.
The PDF has a working index, bookmarks and links between sections, plus the factory wiring diagrams with connector, splice and ground locations. It opens on any computer, phone or tablet without extra software, and you can print the whole manual or only the pages you need.
Inside the 2016 Jeep Cherokee factory manual
Lubrication and Maintenance, Suspension, Differential and Driveline, Brakes, Cooling, Audio, Chassis Electrical, Power Systems, Restraints, Engine, Exhaust, Frame and Bumpers, Fuel System, Steering, Transmission and Transfer Case, Tires and Wheels, Body, Heating and Air Conditioning, Emissions Control. 2016 Jeep Cherokee wiring diagrams are included.
About the 2016 Jeep Cherokee
Model year 2016 is part of the Cherokee KL generation (2014–2023). Most procedures are shared with the other years of this generation, but options, software and wiring changed along the way, which is why the manual is built for your VIN.
Check the model year on your VIN: on a 2016 vehicle the 10th character of the 17-digit VIN is “G”. North American vehicles always use this position for the model year; on some European vehicles it may be unused, so check the registration papers too.
At about 10 years old, a 2016 vehicle often needs cooling system, suspension bushing, engine mount and corroded-connector repairs, where exact factory steps and torque values save hours.
Other years of the same generation: 2014 Jeep Cherokee, 2015 Jeep Cherokee, 2017 Jeep Cherokee, 2018 Jeep Cherokee, 2019 Jeep Cherokee, 2020 Jeep Cherokee, 2021 Jeep Cherokee, 2022 Jeep Cherokee, 2023 Jeep Cherokee.
Versions offered
All configurations covered: 2016 Jeep Cherokee Sport, 2016 Jeep Cherokee Latitude, 2016 Jeep Cherokee Limited, 2016 Jeep Cherokee Trailhawk, 2016 Jeep Cherokee Overland.
Engines:
- Engine, 2.0L Diesel
- Engine, 2.2L Diesel
- Engine, 2.4L Multiair
- Engine, 3.2L
Your manual is built for the version in your VIN.
Video
This video is for information. Your manual looks and works the same way, but it is not identical.
Delivery
Free, direct download link, 12-24 hours.
