2005 Range Rover Sport L320 repair manual

2005 Range Rover Sport L320 OEM service and repair manual – VIN-specific PDF

The 2005 Range Rover Sport L320 factory repair manual, made for your VIN from Land Rover's own service information: removal and installation steps, torque values, diagnostics and wiring diagrams for your exact Range Rover Sport L320. The 2005 Range Rover Sport L320 was offered with three engines (listed below); the manual you get is for the one in your VIN.

The Google Top Quality Store badge, without a subscription. Pay once for this manual; there is no monthly fee and nothing to cancel later.

The difference you get

• Factory information, not an aftermarket book: the same Land Rover procedures and specifications dealer technicians use
• Built for your VIN: only the engine, gearbox and options your Range Rover Sport L320 actually has
• Yours to keep: pay once and the PDF stays with you
• Clickable hyperlinks throughout the PDF: from a repair step straight to the diagram or torque table it mentions, with bookmarks and full-text search on top. Few manuals sold online have this
• Complete wiring diagrams and connector views, not just the mechanical sections
• Online since 2015, rated a Google Top Quality Store

What this manual has that the owner's manual does not

The owner's manual stops where the repair starts. The factory repair manual picks up from there:

• Owner's manual: controls, warning lights, maintenance schedule, fluid types
• Factory repair manual: diagnosis by trouble code, step-by-step repairs, tightening torques, wiring diagrams and connector views

Your 2005 Range Rover Sport L320 is from the first-generation Range Rover Sport (L320), built for model years 2005–2013. It is the first model year of the Range Rover Sport L320, so use procedures for this year only.

Engines offered

• 2.7L Diesel
• 4.2L SC V8 Petrol
• 4.4L V8 Petrol

Transmissions offered

• 6-Speed Automatic 6HP26

The manual is made for the version in your VIN, so you don't have to work out your engine code.

Common work on a 2005 Range Rover Sport L320

• Brake lines, hoses and master cylinder
• Ignition components and idle problems
• Suspension bushings and steering play
• Cooling system overhaul
• Wiring harness, connector and ground repairs
• Glow plugs and cold-start faults
• Diesel particulate filter regeneration
• EGR valve and cooler

What NHTSA records show for the 2005 Range Rover Sport L320

The U.S. safety agency NHTSA lists 1 safety recall and 36 owner complaints for the 2005 Range Rover Sport L320. The factory manual has the procedures for the parts involved.

• Power Train: Driveshaft (campaign 08V635000)

Most owner complaints concern: Power Train (21), Steering (4), Equipment (4), Suspension (3), Electrical System (3).

On a 2005 vehicle the 10th character of the 17-digit VIN is “5”, a quick way to confirm the model year before you order.

Other years of the same generation: 2006 Range Rover Sport L320, 2007 Range Rover Sport L320, 2008 Range Rover Sport L320, 2009 Range Rover Sport L320, 2010 Range Rover Sport L320, 2011 Range Rover Sport L320, 2012 Range Rover Sport L320, 2013 Range Rover Sport L320.

Also for Range Rover: 2018 Velar, 2005 L322, 2013 L405, 2002 P38a, 2012 Evoque, 2014 Sport L494.

How you get it

1. Order and enter your 17-digit VIN.
2. We pull the Land Rover service information for that VIN and put it into one searchable PDF with bookmarks and hyperlinks.
3. The download link arrives by email in 12–24 hours.

What you'll find in the 2005 Range Rover Sport L320 manual

• General information, vehicle identification and lifting points
• Maintenance schedules, fluids and capacities
• Engine mechanical: timing, cylinder head, lubrication
• Cooling system
• Fuel system and engine management
• Ignition, starting and charging
• Emission controls
• Exhaust system
• Clutch and manual transmission
• Automatic transmission / transaxle
• Driveshafts, axles and differential
• Suspension, front and rear
• Steering
• Brakes and ABS
• Heating, ventilation and air conditioning
• Restraints and airbags
• Body, doors, glass and trim
• Lighting and instruments
• Electrical components and module locations
• Wiring diagrams
• Diagnostic trouble codes

Engine

2.7L Diesel

4.2L SC V8 Petrol

4.4L V8 Petrol

Transmission

6-Speed Automatic 6HP26

Your manual is built for the version in your VIN.

This video is for information. Your manual looks and works the same way, but it is not identical.

Free, by email in 12-24 hours.
