2010 Range Rover Sport L320 repair manual

2010 Range Rover Sport L320 factory repair manual – PDF for your VIN

The 2010 Range Rover Sport L320 factory repair manual, made for your VIN from Land Rover's factory service data: removal and installation steps, torque values, diagnostics and wiring diagrams for your exact Range Rover Sport L320. The 2010 Range Rover Sport L320 was offered with four engines and two transmissions (listed below); we build your manual for the combination your VIN shows.

Google rates factory-manuals.com a Top Quality Store, and we do not sell subscriptions. You pay once for the 2010 Range Rover Sport L320 manual and keep the PDF for as long as you own the car.

Why owners choose factory-manuals.com

• Yours to keep: pay once and the PDF stays with you
• Clickable hyperlinks throughout the PDF: from a repair step straight to the diagram or torque table it mentions, with bookmarks and full-text search on top. Few manuals sold online have this
• Complete wiring diagrams and connector views, not just the mechanical sections
• Works on any device, offline, and prints page by page for the garage
• A real person checks every order and the VIN before the manual is built
• Online since 2015, rated a Google Top Quality Store

What this manual has that the owner's manual does not

The owner's manual stops where the repair starts. The factory repair manual picks up from there:

• Owner's manual: controls, warning lights, maintenance schedule, fluid types
• Factory repair manual: how to take parts out and put them back, the torque for every bolt, fault codes and complete wiring diagrams

Model year 2010 is part of the first-generation Range Rover Sport (L320) (2005–2013). Years of the same generation share most procedures; equipment and electrical details still change from year to year, so the manual follows your VIN.

Engines available for the 2010 Range Rover Sport L320

• 3.0L Diesel
• 3.6L Diesel
• 5.0L NA V8 Petrol
• 5.0L SC V8 Petrol

Transmission options

• 6-Speed Automatic 6HP26
• 6-Speed Automatic 6HP28

Your manual is built for your version only: the VIN tells us the exact engine and transmission.

Common work on a 2010 Range Rover Sport L320

• Suspension bushings and steering play
• Cooling system overhaul
• Wiring harness, connector and ground repairs
• Rubber hoses, seals and gaskets
• Rust repair and body panels
• Glow plugs and cold-start faults
• Diesel particulate filter regeneration
• EGR valve and cooler

2010 Range Rover Sport L320: recalls and known problems

The U.S. safety agency NHTSA lists 7 safety recalls and 118 owner complaints for the 2010 Range Rover Sport L320. When a part on this list fails out of warranty, the manual shows how to test and replace it.

• Air Bags: Inflator Module (campaign 18V015000)
• Air Bags: Inflator Module (campaign 18V011000)
• Service Brakes, Hydraulic: Hoses, Lines/Piping, and Fittings (campaign 15V039000)
• Air Bags: Inflator Module (campaign 16V374000)
• Air Bags: Sensor/Control Module-Inactive (campaign 09V467000)
• Fuel System, Gasoline: Mounting Plate/Flange (campaign 21V635000)
• Structure: Body (campaign 20V623000)

Most owner complaints concern: Structure (26), Engine (18), Fuel/Propulsion System (14), Fuel System (14), Gasoline (14).

On a 2010 vehicle the 10th character of the 17-digit VIN is “A”, a quick way to confirm the model year before you order.

Other years of the same generation: 2005 Range Rover Sport L320, 2006 Range Rover Sport L320, 2007 Range Rover Sport L320, 2008 Range Rover Sport L320, 2009 Range Rover Sport L320, 2011 Range Rover Sport L320, 2012 Range Rover Sport L320, 2013 Range Rover Sport L320.

Other Range Rover manuals: 2012 Evoque, 2014 Sport L494, 2010 L322, 2013 L405, 2002 P38a, 2018 Velar.

How you get it

1. Order and enter your 17-digit VIN.
2. We pull the Land Rover service information for that VIN and put it into one searchable PDF with bookmarks and hyperlinks.
3. The download link arrives by email in 12–24 hours.

Contents of the 2010 Range Rover Sport L320 repair manual

• Vehicle identification and general information
• Lubrication and scheduled maintenance
• Engine: removal, overhaul and timing
• Engine cooling
• Fuel and engine controls
• Starting, charging and battery
• Exhaust and emissions
• Transmission and transfer case
• Axles, driveline and wheel bearings
• Front and rear suspension
• Steering column and gear
• Brake system and ABS
• Climate control
• Supplemental restraint system
• Body repair and dimensions
• Interior and exterior trim
• Power windows, locks and mirrors
• Lighting
• Instrument cluster and warning lights
• Wiring diagrams and connector views
• Diagnostics and trouble codes

Engine

3.0L Diesel

3.6L Diesel

5.0L NA V8 Petrol

5.0L SC V8 Petrol

Transmission

6-Speed Automatic 6HP26

6-Speed Automatic 6HP28

Your manual is built for the version in your VIN.

This video is for information. Your manual looks and works the same way, but it is not identical.

Free, by email in 12-24 hours.
