2020 Lincoln MKZ Hybrid repair manual

2020 Lincoln MKZ Hybrid workshop manual: factory repair procedures and wiring diagrams

The 2020 Lincoln MKZ Hybrid factory repair manual, made for your VIN from the same Ford service information dealer technicians use: step-by-step repair procedures, specifications and wiring diagrams for your exact MKZ Hybrid. The 2020 MKZ Hybrid came with the 2.0L Duratec – Hybrid engine.

One payment, one manual, a Google Top Quality Store. Other stores with the badge sell monthly access; we sell the manual outright, yours to keep and reuse.

The difference you get

• Manufacturer data: written by Ford, not rewritten by a third-party publisher
• Matched to your VIN, so you don't wade through versions you don't own
• One payment: no subscription, no login that expires, no monthly fee
• A PDF with working hyperlinks: click a reference in a procedure and you land on the wiring diagram, spec or step it points to. Most PDF manuals sold online are flat scans without them
• Complete wiring diagrams and connector views, not just the mechanical sections
• A real person checks every order and the VIN before the manual is built

Not the owner's manual

Many people search for the 2020 MKZ Hybrid owner's manual and need more than it gives. The difference:

• Owner's manual: controls, warning lights, maintenance schedule, fluid types
• Factory repair manual: removal and installation steps, torque specs, diagnostic trouble codes, wiring diagrams and component locations

The 2020 MKZ Hybrid belongs to the second-generation MKZ Hybrid, model years 2013–2020. It is the last model year of this generation and carries all the running changes made during production.

Engine options

• 2.0L Duratec – Hybrid (103kW/140PS) (UA)

Transmissions offered

• Automatic Transmission – HF35

Your manual is built for your version only: the VIN tells us the exact engine and transmission.

Jobs owners of a 6-year-old MKZ Hybrid look up most

• Sensor faults: oxygen, ABS wheel speed, mass air flow
• Door lock actuators and window regulators
• Brake pads, rotors and calipers
• Suspension links, bushings and wheel bearings
• Spark plugs and ignition coils
• Hybrid battery cooling fan and filter
• Inverter coolant service
• Brake bleeding on the electronic brake system

What NHTSA records show for the 2020 MKZ Hybrid

The U.S. safety agency NHTSA lists 1 safety recall and 2 owner complaints for the 2020 MKZ Hybrid. The factory manual has the procedures for the parts involved.

• Back Over Prevention: Software (campaign 25V442000)

Check your VIN: the 10th character is “L” on a 2020 model.

Other years of the same generation: 2013 MKZ Hybrid, 2014 MKZ Hybrid, 2015 MKZ Hybrid, 2016 MKZ Hybrid, 2017 MKZ Hybrid, 2018 MKZ Hybrid, 2019 MKZ Hybrid.

Also for Lincoln: 2020 Aviator, 2020 Corsair, 2008 Mark LT, 2020 Continental, 2006 LS, 2019 MKC, 2016 MKS, 2019 MKT, 2018 MKX, 2020 MKZ.

What happens after you order

1. We check the VIN.
2. We compile the 2020 MKZ Hybrid service information for it.
3. You receive one bookmarked, hyperlinked PDF by email in 12–24 hours.

Sections of the 2020 MKZ Hybrid service manual

• General information, vehicle identification and lifting points
• Maintenance schedules, fluids and capacities
• Engine mechanical: timing, cylinder head, lubrication
• Cooling system
• Fuel system and engine management
• Ignition, starting and charging
• Emission controls
• Exhaust system
• Clutch and manual transmission
• Automatic transmission / transaxle
• Driveshafts, axles and differential
• Suspension, front and rear
• Steering
• Brakes and ABS
• Heating, ventilation and air conditioning
• Restraints and airbags
• Body, doors, glass and trim
• Lighting and instruments
• Electrical components and module locations
• Wiring diagrams
• Diagnostic trouble codes

Engine

2.0L Duratec – Hybrid (103kW/140PS) (UA)

Transmission

Automatic Transmission – HF35

Your manual is built for the version in your VIN.
