2014 Audi A1 Complete Service Manual PDF
$79.99
- Do the labor yourself. On most repairs the shop’s labor costs more than the parts. With the factory procedure you can do that part yourself.
- Built for your VIN. Your engine, transmission and options, so you don’t have to guess which section applies.
- Factory steps, specs and wiring. Repair procedures with illustrations, torque values and the complete wiring diagrams.
- Find any job in seconds. Searchable PDF with a full index and bookmarks.
- In your inbox in 12–24 hours. Yours to keep, on any computer, phone or tablet.
Description
2014 Audi A1 OEM factory repair manual – VIN-specific PDF download
The 2014 Audi A1 (8X) factory repair manual, taken from Audi's own service information for your VIN: repair procedures, torque specs and wiring diagrams for your exact car. Audi offered the 2014 A1 with eleven engine versions, the 1.0, 1.2, 1.4 and 2.0 petrol engines and 1.4, 1.6 and 2.0 TDI diesels, each with its own gearbox options (listed below); your manual is built for the engine and gearbox in your VIN.
Google Top Quality Store, and no subscription. Other Top Quality Stores rent access by the month. We are the only one selling manuals you keep: one payment, and the PDF stays on your computer for good.
The 2014 Audi A1 belongs to the first-generation A1 (8X), model years 2010–2018. Most procedures are shared with the other years of this generation, but engines, equipment and wiring changed from year to year. The engine line-up is the same as in 2013; what differs is equipment and electrical detail, which is why the wiring diagrams are matched to your VIN.
Engines offered for the 2014 Audi A1
- 1.4 TDI (EA288 Gen. I): CUSB
- 1.0 TFSI (EA211): CHZB, CHZE, DKLD, DDHA
- 1.6 TDI: CAYC, CAYB
- 2.0 TDI: CFHB, CFHD
- 1.6 TDI (EA288 Gen. I): CXMA
- 1.2 TFSI (EA111): CBZA
- 1.4 TFSI (EA111): CAXA, CNVA
- 1.4 TFSI (EA211): CPTA, CZCA, CZEA, CZDB, CZDD
- 2.0 TFSI: DAJB, CWZA
- 1.4 petrol (EA111): CAVG, CNUA, CTHG, CTJA
- 2.0 petrol (EA113): CDLH
You find your engine code on the vehicle data sticker in the spare wheel well and in the service book.
Gearboxes offered
- 5-speed manual: 02R, 0A4
- 5-speed manual: 02T, 0DF
- 6-speed manual: 02U
- 6-speed manual: 0A8, four-wheel drive
- 6-speed manual: 0A8, front-wheel drive
- 7-speed dual clutch: 0AM, 0CW (S tronic)
The EA113 2.0 TFSI wears the cam follower that drives its high-pressure fuel pump and builds carbon on the intake valves; both jobs are covered step by step. On the EA288 2.0 TDI the particulate filter, AdBlue (SCR) system and EGR cooler are the usual jobs, along with the timing belt.
On a 2014 car the 10th character of the VIN is “E”, a quick way to confirm the model year before you order.
Dealer information, organized for one car. Audi technicians look up repairs in Audi's own service system. We take the same information for your VIN, leave out what doesn't apply to your A1 and deliver it as one PDF within 12–24 hours.
Every chapter is bookmarked and linked, from maintenance and brakes to the engine, gearbox and body electrics. The wiring diagrams show each circuit with its connectors, ground points and fitting locations.
What the 2014 Audi A1 manual covers
- General Information and Maintenance
- Engine Mechanical, Cooling and Lubrication
- Fuel Supply and Exhaust System
- Heating, Air Conditioning and Auxiliary Heater
- Brake System and ABS
- Steering and Power Steering Control
- Front and Rear Suspension, Self-Leveling Suspension
- Transmission, Transaxle and Transfer Box
- Driveline, Front and Rear Axle
- Body Repair, Exterior, Interior and Paint
- Doors, Locks, Glass and Window Systems
- Seats, Seat Belts and Airbags
- Wheels, Tires and Vehicle Geometry
- Audio, Visual and Navigation
- Electrical: Charging, Starting and Power Systems
- Exterior and Interior Lighting
- Complete Wiring Diagrams and Fitting Locations
Versions offered
Engines offered for the 2014 Audi A1:
3-cylinder TDI engine, 1.4 ltr. 4-valve common rail (EA 288 Gen. I) CUSB
3-cylinder direct injection engine (1.0 ltr. 4-valve TFSI EA211) CHZB CHZE DKLD DDHA
4-cylinder TDI engine (1.6 ltr. 4-valve common rail) CAYC CAYB
4-cylinder TDI engine (2.0 ltr. 4-valve common rail) CFHB CFHD
4-cylinder TDI engine, 1.6 ltr. 4-valve common rail (EA 288 Gen. I) CXMA
4-cylinder direct injection engine (1.2 ltr. 2-valve TFSI EA111) CBZA
4-cylinder direct injection engine (1.4 ltr. 4-valve TFSI EA111) CAXA CNVA
4-cylinder direct injection engine (1.4 ltr. 4-valve TFSI EA211) CPTA CZCA CZEA CZDB CZDD
4-cylinder direct injection engine (1.8, 2.0 ltr. 4-valve TFSI - generation III) DAJB CWZA
4-cylinder direct petrol injection engine (1.4 ltr. 4-valve turbo with supercharger EA111) CAVG CNUA CTHG CTJA
4-cylinder direct petrol injection engine (2.0 ltr. 4-valve turbo EA113) CDLH
Transmissions offered for the 2014 Audi A1:
5-speed manual gearbox 02R, 0A4
5-speed manual gearbox 02T, 0DF
6-speed manual gearbox 02U
6-speed manual gearbox 0A8, four-wheel drive
6-speed manual gearbox 0A8, front-wheel drive
7-speed dual clutch gearbox 0AM, 0CW (S tronic)
Your manual is built for the version in your VIN.
