2020 Hyundai Elantra repair manual

2020 Hyundai Elantra workshop manual (AD): factory repair procedures and wiring diagrams

The 2020 Hyundai Elantra (AD) factory repair manual, made for your VIN from the same Hyundai service information dealer technicians use: removal and installation steps, torque values, diagnostics and wiring diagrams for your exact Elantra. The 2020 Elantra was offered with four engines and three transmissions (listed below); the manual you get is for the combination in your VIN.

Google rates factory-manuals.com a Top Quality Store, and we do not sell subscriptions. You pay once for the 2020 Elantra manual and keep the PDF for as long as you own the car.

Why owners choose factory-manuals.com

• Factory information, not an aftermarket book: the same Hyundai procedures and specifications dealer technicians use
• Built for your VIN: only the engine, gearbox and options your Elantra actually has
• One payment: no subscription, no login that expires, no monthly fee
• A PDF with working hyperlinks: click a reference in a procedure and you land on the wiring diagram, spec or step it points to. Most PDF manuals sold online are flat scans without them
• Wiring included: diagrams, connector pinouts and component locations
• A real person checks every order and the VIN before the manual is built

Owner's manual or repair manual?

The owner's manual in the glovebox explains the controls and the service intervals. This is the other book, the one technicians work from:

• Owner's manual: controls, warning lights, maintenance schedule, fluid types
• Factory repair manual: how to take parts out and put them back, the torque for every bolt, fault codes and complete wiring diagrams

The 2020 Elantra belongs to the sixth-generation Elantra (AD), model years 2017–2020. It is the last model year of this generation and carries all the running changes made during production.

Engines available for the 2020 Elantra

• G 1.6 T-GDI
• G 1.4 T-GDI
• G 2.0 MPI
• G 2.0 GDI

Transmission options

• Manual Transaxle System (M6CF3-1)
• DCT (Dual Clutch Transmission) System (Dual Clutch Transmission) D7GF1
• Intelligent Variable Transmission (IVT) C0GF1

The manual is made for the version in your VIN, so you don't have to work out your engine code.

Typical repairs for a 2020 Elantra

• Sensor faults: oxygen, ABS wheel speed, mass air flow
• Door lock actuators and window regulators
• Brake pads, rotors and calipers
• Suspension links, bushings and wheel bearings
• Spark plugs and ignition coils
• Boost leaks and intercooler hoses
• Turbocharger oil feed and return lines

2020 Elantra: recalls and known problems

The U.S. safety agency NHTSA lists 3 safety recalls and 254 owner complaints for the 2020 Elantra. The repair steps for these systems are in the manual.

• Engine (campaign 21V301000)
• Wheels: Lugs/Nuts/Bolts/Studs (campaign 19V720000)
• Suspension: Lower Ball Joint (campaign 19V721000)

Most owner complaints concern: Engine (109), Power Train (47), Exterior Lighting (28), Electrical System (27), Unknown or Other (26).

On a 2020 vehicle the 10th character of the 17-digit VIN is “L”, a quick way to confirm the model year before you order.

Other years of the same generation: 2017 Elantra, 2018 Elantra, 2019 Elantra.

Other Hyundai manuals: 2010 Entourage, 2020 Grand i10, 2020 Azera, 2020 Creta, 2016 Equus, 2024 Exter, 2017 Genesis, 2020 Ioniq, 2022 Ioniq 5, 2023 Ioniq 6.

How it works: you order with your VIN, we put together the Hyundai service information for that vehicle, and the PDF reaches your inbox in 12–24 hours. It works offline and prints page by page.

Inside the manual

• Vehicle identification and general information
• Lubrication and scheduled maintenance
• Engine: removal, overhaul and timing
• Engine cooling
• Fuel and engine controls
• Starting, charging and battery
• Exhaust and emissions
• Transmission and transfer case
• Axles, driveline and wheel bearings
• Front and rear suspension
• Steering column and gear
• Brake system and ABS
• Climate control
• Supplemental restraint system
• Body repair and dimensions
• Interior and exterior trim
• Power windows, locks and mirrors
• Lighting
• Instrument cluster and warning lights
• Wiring diagrams and connector views
• Diagnostics and trouble codes

Engines offered for the 2020 Hyundai Elantra:
 G 1.6 T-GDI
 G 1.4 T-GDI
 G 2.0 MPI
 G 2.0 GDI

Transmissions offered for the 2020 Hyundai Elantra:
 Manual Transaxle System (M6CF3-1)
 DCT (Dual Clutch Transmission) System (Dual Clutch Transmission) D7GF1
 Intelligent Variable Transmission (IVT) C0GF1

Your manual is built for the version in your VIN.

This video is for information. Your manual looks and works the same way, but it is not identical.

Free, by email in 12-24 hours.
