2020 Jeep Gladiator repair manual
$69.99
- Do the labor yourself. On most repairs the shop’s labor costs more than the parts. With the factory procedure you can do that part yourself.
- Built for your VIN. Your engine, transmission and options, so you don’t have to guess which section applies.
- Factory steps, specs and wiring. Repair procedures with illustrations, torque values and the complete wiring diagrams.
- Find any job in seconds. Searchable PDF with a full index and bookmarks.
- In your inbox in 12–24 hours. Yours to keep, on any computer, phone or tablet.
Description
2020 Jeep Gladiator repair manual - OEM Factory Repair Manual
The 2020 Jeep Gladiator (JT) factory repair manual, built from Chrysler's own service information for your VIN: every repair procedure, torque spec and wiring diagram for your exact truck. It covers the 3.6 Pentastar V6 with the 6-speed manual or 8-speed automatic, on every trim from Sport to Rubicon.
Google Top Quality Store, and no subscription. Other Top Quality Stores rent access by the month. We are the only one selling manuals you keep: one payment, and the PDF stays on your computer for good.
2020 is the first model year of the Gladiator (JT). From the cab forward it shares most of its parts with the Wrangler JL; behind the cab it gets a longer frame, a 137.3-inch wheelbase and a 5-foot steel bed. The doors, top and windshield come off just like on the Wrangler, so the door harness connectors and the windshield frame procedures are in the manual too.
Every 2020 truck has the 3.6-liter Pentastar V6, with either the 6-speed manual or the 8-speed automatic. The 3.0 EcoDiesel only arrived for 2021, so a 2020 manual has no diesel sections to wade through. All trims use a Dana 44 rear axle; the Rubicon adds a Dana 44 up front, electric lockers and a disconnecting front sway bar.
What owners look up most on these trucks: front-end shimmy at highway speed (steering damper, track bar and tie rod ends, with the torque value for every bolt), checking and filling the 8-speed automatic, and the bed lighting and trailer wiring. On a 2020 truck the 10th character of the VIN is “L”.
Factory information, organized for one vehicle. Dealer technicians look up repairs in Chrysler's service system. We take the same information for your VIN, leave out what doesn't apply to your Jeep and deliver it as one PDF within 12–24 hours.
Every section is bookmarked and linked, from maintenance and brakes to the engine, transmission and body electrical. The wiring diagrams show each circuit with its connectors, splices and grounds, which is what you need most for electrical faults.
What a 2020 Jeep Gladiator service manual covers
Lubrication and Maintenance, Suspension, Differential and Driveline, Brakes, Clutch, Cooling, Audio, Chassis Electrical, Power Systems, Restraints, Engine, Exhaust, Frame and Bumpers, Fuel System, Steering, Transmission and Transfer Case, Tires and Wheels, Body, Heating and Air Conditioning, Emissions Control. 2020 Jeep Gladiator wiring diagrams are included.
About the 2020 Jeep Gladiator
The 2020 Jeep Gladiator belongs to the Gladiator JT generation, model years 2020–2026. It is the first model year of this generation, so body, wiring and many procedures differ from the model before it.
At about 6 years old, a 2020 vehicle is usually out of its basic warranty; brakes, suspension, fluids, the 12-volt battery and sensor faults are the typical jobs.
Other years of the same generation: 2021 Jeep Gladiator, 2022 Jeep Gladiator, 2023 Jeep Gladiator, 2024 Jeep Gladiator.
Versions offered
2020 Jeep Gladiator Configurations:
2020 Jeep Gladiator Sport
-
3.6L Pentastar® V6 engine with 285 HP
-
Uconnect® 3 infotainment interface
-
8-speaker sound system
-
5-inch touchscreen display
2020 Jeep Gladiator Sport S
-
Automatic headlights
-
17-inch Tech Silver aluminum wheels
-
Power windows and locks
2020 Jeep Gladiator Overland
-
7-inch touchscreen display
-
Standard Apple CarPlay™ and Android Auto®
-
Additional USB Ports
-
Uconnect® 4 Infotainment interface
-
Overland exclusive cloth upholstery with embroidery
-
18-inch Granite Crystal aluminum wheels
2020 Jeep Gladiator Rubicon
-
Front and rear locking differentials
-
Sway bar, rock rails, and brush guard
-
Ambient interior LED lighting
-
4:1 Rock-Trac® Heavy-Duty Part-Time 4WD System
-
33-Inch LT285 / 70R17C All-Terrain Tires
-
Rubicon exclusive cloth upholstery with embroidery
Your manual is built for the version in your VIN.
Video
This video is for information. Your manual looks and works the same way, but it is not identical.
Delivery
Free, direct download link, 12-24 hours.
