2016 Jeep Wrangler repair manual
$69.99
- Do the labor yourself. On most repairs the shop’s labor costs more than the parts. With the factory procedure you can do that part yourself.
- Built for your VIN. Your engine, transmission and options, so you don’t have to guess which section applies.
- Factory steps, specs and wiring. Repair procedures with illustrations, torque values and the complete wiring diagrams.
- Find any job in seconds. Searchable PDF with a full index and bookmarks.
- In your inbox in 12–24 hours. Yours to keep, on any computer, phone or tablet.
Description
2016 Jeep Wrangler repair manual - OEM Factory Repair Manual
The 2016 Jeep Wrangler (JK) factory repair manual, built from Chrysler's own service information for your VIN: every repair procedure, torque spec and wiring diagram for your exact Jeep. It covers the 3.6 Pentastar V6 with the 6-speed manual or 5-speed automatic, including the 75th Anniversary and special editions sold that year.
Look for the Top Quality Store badge. Google shows it next to factory-manuals.com, and we are the only store with that badge that sells you the manual itself, not timed access. Pay once and keep it.
2016 was Jeep's 75th anniversary year, and a lot of special-edition Wranglers were built on the standard JK mechanicals: Pentastar V6, 6-speed manual or 5-speed automatic, Dana 30 or Dana 44 front axles depending on the trim. The VIN tells us exactly which parts your Jeep has.
At this age the usual work is suspension and steering (track bar, tie rod ends, control arm bushings), brake service, and the cooling system. The manual also covers the soft top and hardtop removal, the door wiring and the rear window defroster circuits.
On a 2016 Jeep the 10th character of the VIN is “G”, an easy way to confirm the model year before you order.
How we make your manual. Chrysler sells access to its factory service information to owners and independent shops. We do that work for you: we open the service information for your VIN and build a PDF that matches your engine, transmission and options. It takes 12–24 hours. If your Jeep is apart right now, choose priority delivery and you get it in 4–6 hours.
The PDF has a working index, bookmarks and links between sections, plus the factory wiring diagrams with connector, splice and ground locations. It opens on any computer, phone or tablet without extra software, and you can print the whole manual or only the pages you need.
Inside the 2016 Jeep Wrangler factory manual
Lubrication and Maintenance, Suspension, Differential and Driveline, Brakes, Clutch, Cooling, Audio, Chassis Electrical, Power Systems, Restraints, Engine, Exhaust, Frame and Bumpers, Fuel System, Steering, Transmission and Transfer Case, Tires and Wheels, Body, Heating and Air Conditioning, Emissions Control. 2016 Jeep Wrangler wiring diagrams are included.
About the 2016 Jeep Wrangler
Your 2016 Jeep Wrangler is from the Wrangler JK generation, which covers model years 2007–2017. Most procedures are shared with the other years of this generation, but options, software and wiring changed along the way, which is why the manual is built for your VIN.
At about 10 years old, a 2016 vehicle often needs cooling system, suspension bushing, engine mount and corroded-connector repairs, where exact factory steps and torque values save hours.
Other years of the same generation: 2010 Jeep Wrangler, 2011 Jeep Wrangler, 2012 Jeep Wrangler, 2013 Jeep Wrangler, 2014 Jeep Wrangler, 2015 Jeep Wrangler, 2017 Jeep Wrangler.
Versions offered
All configurations covered: 2016 Jeep Wrangler Sport, 2016 Jeep Wrangler Rubicon, 2016 Jeep Wrangler Unlimited Sport, 2016 Jeep Wrangler Sahara, 2016 Jeep Wrangler Unlimited Sport RHD.
Engines:
- Engine, 2.8L Diesel
- Engine, 3.0L Gasoline
- Engine, 3.6L
Your manual is built for the version in your VIN.
Video
This video is for information. Your manual looks and works the same way, but it is not identical.
Delivery
Free, direct download link, 12-24 hours.
